Ceiling Clouds

Ceiling Clouds are perfect for the reduction of sound in ceiling areas. They are suspended horizontally with D-Rings (for panels up to 4’ x 4’) or T-grid attachment for larger panels.

Ceiling Clouds are constructed with a 6-7# PCF rigid fiberglass absorber core. The edges are available in natural or chemically hardened and are available in 4 edge profiles.

Ceiling Cloud Products:
Suspended Acoustic Solutions

Photograph

Ceiling Clouds are perfect for the reduction of sound in ceiling areas. They are suspended horizontally with D-Rings (for panels up to 4’ x 4’) or T-grid attachment for larger panels.

Ceiling Clouds are constructed with a 6-7# PCF rigid fiberglass absorber core. The edges are available in natural or chemically hardened and are available in 4 edge profiles.

Guilford of Maine FR701 Style 2100 is the industry standard. Hundreds of approved decorative fabrics are also available from numerous manufacturers including, but not limited to: Guilford of Maine, Maharam, Design Tex and Knoll. Customers may also specify their own fabric, provided the material meets manufacturing requirements.

Acoustic Applications – Auditoriums, Industrial Acoustics and more

Commercial Ceiling Clouds

PhotographCommercial Ceiling Clouds is free-hanging fiberglass ceiling panel. It offers a high-recycled content (71% total, 70% post-consumer, 1% pre-consumer). The LEED calculation for this products recycled content is 71%. The acoustical performance of this product may contribute to points for a LEED project per that U.S. Green Building Council system.

Energy and Atmosphere (EA)
Credit 1 Optimize energy performance
Our ceiling panels with high light reflectance (above 0.82 according to ASTM E1477) can reduce lighting demands and subsequently the energy required to operate them. 1-10 points. Acoustic Applications – Auditoriums, Industrial Acoustics and more

Ceiling Cloud Details:

Wall Panel Substrate: 6-7# PCF rigid fiberglass core with optional chemically hardened edges.

Sound Absorption Ceiling Cloud Edge Details: Square, Bevel, Radius, Miter

Sound Absorption Ceiling Cloud Mounting: Eye hooks, T-grid

Acoustical Ceiling Cloud NRC Ratings

1/2″ .50-.60
1″ .80-.90
1 &frac12 .90-1.00
2″ 1.05-1.15
Noise Control Applications

Froggtown Inn & Acres Restaurant has retrofitted our clouds to their existing dinning room to create a quieter and more private conversation environment by using All Noise Control clouds. Pictures courtesy of Froggtown Inn & Restaurant. Read More.

 Ceiling Cloud Specs



Case Studies:

Ceiling clouds for Restaurants. Read More.

Installations:
Colors:

Fiberglass Panels - Ceiling Clouds acoustic treatments. Shown here suspended with T-Grid

Contact Noise Control Specialists for FREE Consultation (561) 964-9360 or send us a message using our Online form
